ADRF6655
Rev. 0 | Page 15 of 44
COMPLIMENTARY CUMULATIVE DISTRIBUTION FUNCTION (CCDF): DOWNCONVERSION, LO = 1700 MHz,
RF = 1900 MHz
VS = 5 V, TA = 25°C, PFD = 20 MHz, REFIN = 20 MHz, IP3SET = open, as measured using typical downconversion circuit schematic with
high-side LO and 200 MHz IF output, unless otherwise noted.
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
–5 –4 –3 –2 –1 0 1
GAIN, INPUT P1dB (dB, dBm)
+25°C
–40°C
+85°C
IP3SET = 3.2V
IP3SET = OPEN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
GAIN
INPUT P1dB
Figure 38. Gain and Input P1dB
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
INPUT IP3 (dBm)
+25°C
–40°C
+85°C
IP3SET = 3.2V
IP3SET = OPEN
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
Figure 39. Rx Input IP3
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
–100
–90
–80
–70
–60
–50
–40
–30
+25°C
–40°C
+85°C
IP3SET = 3.2V
IP3SET = OPEN
LO-TO-RF LEAKAGE (dBm)
Figure 40. Rx LO-to-RF Leakage
012
3456789 10 11 12 13 14 15 16 17 18 19 20
NOISE FIGURE (dB)
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
+25°C
–40°C
+85°C
IP3SET = 3.2V
IP3SET = OPEN
Figure 41. Rx Noise Figure CCDF
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
VPTAT (V)
+25°C
–40°C
+85°C
IP3SET = 3.2V
IP3SET = OPEN
0.5
0.7
0.9
1.1
1.3
1.5
1.7
1.9
2.1
2.3
2.5
Figure 42. VPTAT MUXOUT Voltage
