Overrun Bit

The overrun bit is set when new data replaces unread data. The

precise operation of the overrun function depends on the FIFO

mode. In bypass mode, the overrun bit is set when new data

replaces unread data in the DATAX, DATAY, and DATAZ registers

(Address 0x32 to Address 0x37). In all other modes, the overrun

bit is set when FIFO is filled. The overrun bit is automatically

cleared when the contents of FIFO are read.

Orientation Bit

The orientation bit is set when the orientation of the accelerometer

changes from a valid orientation to a different valid orientation.

An interrupt is not generated, however, if the orientation of the

accelerometer changes from a valid orientation to an invalid

orientation, or from a valid orientation to an invalid orientation

and then back to the same valid orientation. An invalid orientation

is defined as an orientation within the dead zone, or the region of

hysteresis. This region helps to prevent rapid orientation change

due to noise when the accelerometer orientation is close to the

boundary between two valid orientations.

The orientations that are valid for the interrupt depend on which

mode, 2D or 3D, is linked to the orientation interrupt. The mode is

selected with the INT_3D bit (Bit D3) in the ORIENT_CONF

(Read/Write) section for more details on how to enable the

orientation interrupt.

FIFO

The ADXL346 contains technology for an embedded memory

management system with 32-level FIFO that can be used to

minimize host processor burden. This buffer has four modes:

bypass, FIFO, stream, and trigger (see Table 22). Each mode is

selected by the settings of the FIFO_MODE bits (Bits[D7:D6])

in the FIFO_CTL register (Address 0x38).

Bypass Mode

In bypass mode, FIFO is not operational and, therefore,

remains empty.

FIFO Mode

In FIFO mode, data from measurements of the x-, y-, and z-axes

are stored in FIFO. When the number of samples in FIFO

equals the level specified in the samples bits of the FIFO_CTL

continues accumulating samples until it is full (32 samples from

measurements of the x-, y-, and z-axes) and then stops collecting

data. After FIFO stops collecting data, the device continues to

operate; therefore, features such as tap detection can be used

after FIFO is full. The watermark interrupt continues to occur

until the number of samples in FIFO is less than the value

stored in the samples bits of the FIFO_CTL register.

Stream Mode

In stream mode, data from measurements of the x-, y-, and z-

axes are stored in FIFO. When the number of samples in FIFO

equals the level specified in the samples bits of the FIFO_CTL

continues accumulating samples and holds the latest 32 samples

from measurements of the x-, y-, and z-axes, discarding older

data as new data arrives. The watermark interrupt continues

occurring until the number of samples in FIFO is less than the

value stored in the samples bits of the FIFO_CTL register.

Trigger Mode

In trigger mode, FIFO accumulates samples, holding the latest

32 samples from measurements of the x-, y-, and z-axes. After

a trigger event occurs and an interrupt is sent to the INT1 or

INT2 pin (determined by the trigger bit in the FIFO_CTL register),

FIFO keeps the last n samples (where n is the value specified by

the samples bits in the FIFO_CTL register) and then operates in

FIFO mode, collecting new samples only when FIFO is not full.

A delay of at least 5 μs should be present between the trigger event

occurring and the start of reading data from the FIFO to allow

the FIFO to discard and retain the necessary samples. Additional

trigger events cannot be recognized until the trigger mode is

reset. To reset the trigger mode, set the device to bypass mode

and then set the device back to trigger mode. Note that the FIFO

data should be read first because placing the device into bypass

mode clears FIFO.

Retrieving Data from FIFO

The FIFO data is read through the DATAX, DATAY, and DATAZ

registers (Address 0x32 to Address 0x37). When the FIFO is in

FIFO, stream, or trigger mode, reads to the DATAX, DATAY,

and DATAZ registers read data stored in the FIFO. Each time

data is read from the FIFO, the oldest x-, y-, and z-axes data are

placed into the DATAX, DATAY, and DATAZ registers.

If a single-byte read operation is performed, the remaining bytes of

data for the current FIFO sample are lost. Therefore, all axes of

interest should be read in a burst (or multiple-byte) read operation.

To ensure that the FIFO has completely popped (that is, that new

data has completely moved into the DATAX, DATAY, and DATAZ

registers), there must be at least 5 μs between the end of reading

the data registers and the start of a new read of the FIFO or a

read of the FIFO_STATUS register (Address 0x39). The end of

reading a data register is signified by the transition of data from

For SPI operation at 1.6 MHz or less, the register addressing

portion of the transmission is a sufficient delay to ensure that

the FIFO has completely popped. For SPI operation greater than

1.6 MHz, it is necessary to deassert the CS pin to ensure a total

delay of 5 μs; otherwise, the delay will not be sufficient. The total

delay necessary for 5 MHz operation is at most 3.4 μs. This is

not a concern when using I2C mode because the communication

rate is low enough to ensure a sufficient delay between FIFO reads.

Rev. C | Page 20 of 40
