Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 949 of 1468
REJ09B0412-0200
(3)
High-Level Pulse Width Selection
Table 19.13 shows possible settings for bits IrCKS2 to IrCKS0 (minimum pulse width), and this
LSI's operating frequencies and bit rates, for making the pulse width shorter than 3/16 times the bit
rate in transmission.
Table 19.13 IrCKS2 to IrCKS0 Bit Settings
Operating
Bit Rate (bps) (Upper Row)/Bit Interval
× 3/16 (µs) (Lower Row)
Frequency
2400
9600
19200
38400
57600
115200
P
φ (MHz)
78.13
19.53
9.77
4.88
3.26
1.63
7.3728
100
100
100
100
100
100
8
100
100
100
100
100
100
9.8304
100
100
100
100
100
100
10
100
100
100
100
100
100
12
101
101
101
101
101
101
12.288
101
101
101
101
101
101
14
101
101
101
101
101
101
14.7456
101
101
101
101
101
101
16
101
101
101
101
101
101
17.2032
101
101
101
101
101
101
18
101
101
101
101
101
101
19.6608
101
101
101
101
101
101
20
101
101
101
101
101
101
25
110
110
110
110
110
110
30
110
110
110
110
110
110
33
110
110
110
110
110
110
35
110
110
110
110
110
110
