Section 24 RAM
Rev. 2.00 Sep. 24, 2008 Page 1103 of 1468
REJ09B0412-0200
Section 24 RAM
This LSI has a high-speed static RAM. The RAM is connected to the CPU by a 32-bit data bus,
enabling one-state access by the CPU to all byte data, word data, and longword data.
The RAM can be enabled or disabled by means of the RAME bit in the system control register
(SYSCR). For details on SYSCR, refer to section 3.2.2, System Control Register (SYSCR).
The RAM size is 56 Kbytes in the H8SX/1668R and H8SX/1668M, 40 Kbytes in the
H8SX/1664R, H8SX/1664M, H8SX/1663R, and the H8SX/1663M.
Product Classification
RAM Size
RAM Addresses
H8SX/1663R
H8SX/1663M
H8SX/1664R
H8SX/1664M
40 Kbytes
H'FF2000 to H'FFBFFF
Flash memory version
H8SX/1668R
H8SX/1668M
56 Kbytes
H'FEE000 to H'FFBFFF
