background image
Data Sheet
ADA4255
REGISTER DETAILS
analog.com
Rev. 0 | 55 of 64
ANALOG ERROR MASK REGISTER
(ANALOG_ERR_DIS) DETAILS
The ANALOG_ERR_DIS register can be used to mask individual error flags in the ANALOG_ERR register. Setting bits in ANALOG_ERR_DIS
to 1 disables the corresponding error flag.
Table 24. ANALOG_ERR_DIS Register Details (Register 0x0A)
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Bit Name
G_RST_
DIS
POR_HV_
DIS
Reserved
WB_ERR_
DIS
MUX_PROT_DIS
OUTPUT_ERR_DIS
INPUT_
ERR_DIS
MUX_OVER_VOLT_ERR_DIS
Access
R/W
R/W
Reserved
R/W
R/W
R/W
R/W
R/W
Reset
0
0
Reserved
0
0
0
0
0
Bit 7, G_RST_DIS—Disable Gain Reset Error
Flag
The G_RST_DIS bit disables the G_RST error flag
Bit 6, POR_HV_DIS—Disable High Voltage
Power Reset Flag
The POR_HV_DIS bit disables the POR_HV error flag.
Bit 4, WB_ERR_DIS—Disable Wire Break
Detection Flag
The WB_ERR_DIS bit disables the WB_ERR error flag.
Bit 3, MUX_PROT_DIS—Disable Input
Multiplexer Protection
By default, the input multiplexer does not allow both sets of inputs
to be connected at the same time (this is a safety feature). This
protection can be disabled by setting MUX_PROT_DIS to 1.
Bit 2, OUTPUT_ERR_DIS—Disable Output
Amplifier Error Flag
The OUTPUT_ERR_DIS bit disables the OUTPUT_ERR error flag.
Bit 1, INPUT_ERR_DIS—Disable Input Amplifier
Error Flag
The INPUT_ERR_DIS bit disables the INPUT_ERR error flag.
Bit 0, MUX_OVER_VOLT_ERR_DIS—Disable
Multiplexer Overvoltage Flag
The MUX_OVER_VOLT_ERR_DIS bit disables the
MUX_OVER_VOLT_ERR error flag.
