651 / 1504 page  Section 13 I/O Ports Rev. 2.00 Sep. 24, 2008 Page 619 of 1468 REJ09B0412-0200 (3) P35/PO13/TIOCA1/TIOCB1/TCLKC-A/ DACK1-B/EDACK3 The pin function is switched as shown below according to the combination of the EXDMAC, DMAC, TPU, and PPG register settings and P35DDR bit setting. Setting EXDMAC DMAC TPU PPG I/O Port Module Name Pin Function EDACK3_OE DACK1B_OE TIOCB1_OE PO13_OE P35DDR EXDMAC EDACK3 output 1 DMAC DACK1-B output 0 1 TPU TIOCB1 output 0 0 1 PPG PO13 output 0 0 0 1 P35 output 0 0 0 0 1 I/O port P35 input (initial value) 0 0 0 0 0 (4) P34/PO12/TIOCA1/ TEND1-B/ETEND3 The pin function is switched as shown below according to the combination of the EXDMAC, DMAC, TPU, and PPG register settings and P34DDR bit setting. Setting EXDMAC DMAC TPU PPG I/O Port Module Name Pin Function ETEND3_OE TEND1B_OE TIOCA1_OE PO12_OE P34DDR EXDMAC ETEND3 output 1 DMAC TEND1-B output 0 1 TPU TIOCA1 output 0 0 1 PPG PO12 output 0 0 0 1 P34 output 0 0 0 0 1 I/O port P34 input (initial value) 0 0 0 0 0 |
|
