Section 20 USB Function Module (USB)
Rev. 2.00 Sep. 24, 2008 Page 1003 of 1468
REJ09B0412-0200
20.5.2
Cable Disconnection
USB function
Application
Cable connected
VBUS pin = 1
USB cable disconnection
VBUS pin = 0
UDC core reset
End
Figure 20.3 Cable Disconnection Operation
The above flowchart shows the operation in section 20.9, Example of USB External Circuitry.
20.5.3
Suspend and Resume Operations
(1)
Suspend Operation
If the USB bus enters the suspend state from the non-suspend state, perform the operation as
shown in figure 20.4.
