background image
Section 13 I/O Ports
Rev. 2.00 Sep. 24, 2008 Page 637 of 1468
REJ09B0412-0200
13.2.11
Port F
(1)
PF7/A23
The pin function is switched as shown below according to the combination of operating mode, the
EXPE bit, the port function control register (PFCR), and the PF7DDR bit settings.
Setting
I/O Port
Module Name
Pin Function
A23_OE
PF7DDR
Bus controller
A23 output*
1
PF7 output
0
1
I/O port
PF7 input
(initial value)
0
0
Note:
*
Valid in external extended mode (EXPE = 1)
(2)
PF6/A22
The pin function is switched as shown below according to the combination of operating mode, the
EXPE bit, the port function control register (PFCR), and the PF6DDR bit settings.
Setting
I/O Port
Module Name
Pin Function
A22_OE
PF6DDR
Bus controller
A22 output*
1
PF6 output
0
1
I/O port
PF6 input
(initial value)
0
0
Note:
*
Valid in external extended mode (EXPE = 1)
