672 / 1504 page  Section 13 I/O Ports Rev. 2.00 Sep. 24, 2008 Page 640 of 1468 REJ09B0412-0200 (7) PF1/A17 The pin function is switched as shown below according to the combination of operating mode, the EXPE bit, the port function control register (PFCR), and the PF1DDR bit settings. Setting I/O Port MCU Operating Mode Module Name Pin Function A17_OE PF1DDR On-chip ROM disabled extended mode Bus controller A17 output Bus controller A17 output* 1 PF1 output 0 1 Modes other than on-chip ROM disabled extended mode I/O port PF1 input (initial value) 0 0 Note: * Valid in external extended mode (EXPE = 1) (8) PF0/A16 The pin function is switched as shown below according to the combination of operating mode, the EXPE bit, the port function control register (PFCR), and the PF0DDR bit settings. Setting I/O Port MCU Operating Mode Module Name Pin Function A16_OE PF0DDR On-chip ROM disabled extended mode Bus controller A16 output Bus controller A16 output* 1 PF0 output 0 1 Modes other than on-chip ROM disabled extended mode I/O port PF0 input (initial value) 0 0 Note: * Valid in external extended mode (EXPE = 1) |
|
