Section 13 I/O Ports

Rev. 2.00 Sep. 24, 2008 Page 647 of 1468

REJ09B0412-0200

13.2.15

Port K

The pin function of port K can be switched with that of port E according to the combination of

operating mode, the EXPE bit, and the PCJKE bit settings. The pin function of port K can be

switched according to the PCJKE bit setting in the single-chip mode (EXPE = 0). However, do not

change the setting of the PCJKE bit in external extended mode. For details, see section 13.3.12,

Port Function Control Register D (PFCRD).

(1)

PK7/PO31/TIOCA11/TIOCB11

The pin function is switched as shown below according to the combination of register setting of

PPG and TPU, setting of the port function control register (PFCR), and the PK7DDR bit settings.

Setting

PPG

TPU

I/O Port

Module Name

Pin Function

PO31_OE

TIOCB11_OE

PK7DDR

PPG

PO31 output*



TPU

TIOCB11 output*



PK7 output*

I/O port

PK7 input*

Note:

Valid when PCJKE = 1.

(2)

PK6/PO30/TIOCA11

The pin function is switched as shown below according to the combination of register setting of

PPG and TPU, setting of the port function control register (PFCR), and the PK6DDR bit settings.

Setting

PPG

TPU

I/O Port

Module Name

Pin Function

PO30_OE

TIOCA11_OE

PK6DDR

PPG

PO30 output*



TPU

TIOCA11 output*



PK6 output*

I/O port

PK6 input*

Note:

Valid when PCJKE = 1.
